Spiral Classifier FG-500 for Copper Ore Processing

I. Project Overview

Project Location: Shaoguan, Guangdong

Main Contractor: BGRIMM Machinery & Automation Technology Co., Ltd.

Product Name: Spiral Classifier

Product Model: FG-500

Scope of Supply: Complete equipment unit

II. Project Description

For a mineral processing plant project in Guangdong undertaken by BGRIMM Machinery & Automation Technology Co., Ltd., the client conducted multiple inspections and ultimately selected Zhengzhou Mining Machinery's Spiral Classifier FG-500. This classifier works in conjunction with the client's existing ball mill to form a closed-circuit system, classifying ground copper‑sulfide ore after milling.

III. Equipment Parameters

No.	Parameter	Unit	Value/Specification	Remarks
1	Specification	–	FG-500
2	Type	–	High‑weir single‑spiral
3	Spiral Diameter	mm	Φ500
4	Spiral Pitch	mm	250
5	Tank Dimensions	mm	4500×560×380
6	Tank Inclination Angle	°	14–18
7	Spiral Rotation Speed	r/min	0.86–8.6
8	Material Processed	–	Ground copper‑sulfide ore
9	Ore Density	g/cm³	2.5–3
10	Overflow Capacity	t/d	21–75
11	Sand‑Return Capacity	t/d	145–261
12	Max. Spiral Lifting Height	mm	300
13	Drive Motor	Model	YVF‑112M‑6	Variable‑frequency drive
		Power	kW	2.2
		Voltage	V	380
		Frequency	Hz	50
		Speed	r/min	100–1000
14	Drive Reducer	Model	WPS155‑50
		Ratio	i=50
15	Equipment Weight (excl. starter cabinet)	t	1.85

Spiral Classifier.jpg

Date：2025.10.21
