Gypsum Powder Production Line
  • Processing capacity
    50,000-300,000 tons/year
  • Processing materials
    phosphogypsum, desulfurized gypsum, industrial by-product gypsum
  • Process method
    one-step method, two-step method
Gypsum Powder Production Line
  • Product FEATURE

According to the product use, by adjusting the rotary kiln speed and steam consumption, the initial setting time of gypsum powder can be adjusted and controlled.
1. The gypsum rotary kiln pipeline contains high-pressure steam, adopts low-temperature and slow-speed heat exchange, has a large heat exchange area, and the temperature of the heat exchange medium is more constant, and the calcination process is easier to control.
2. The gypsum rotary kiln has large volume, large processing capacity, more sufficient drying and calcination, and more stable products.
3. The one-step method simplifies the process, and the drying and calcination are continuously completed in the same equipment, and the control is simple, and the supporting equipment and control links are reduced.


Gypsum is a monoclinic mineral and a hydrate whose main chemical component is calcium sulfate (CaSO4). Gypsum is a widely used industrial material and building material. It can be used as cement retarder, building products, model making, medical food additives, sulfuric acid production, paper filler, paint filler, etc. The most widely used natural gypsum is dihydrate gypsum. Its active ingredient is calcium sulfate dihydrate (CaSO4·2H2O). Generally, gypsum is graded according to the content of calcium sulfate dihydrate in the ore. High-grade gypsum is mostly used as raw material for the production of special gypsum products, such as food, medical, artwork, models and chemical fillers; gypsum mines with calcium sulfate dihydrate content of less than 60% are rarely used; more than 60% The gypsum ore, depending on its content, is used in various fields such as building materials and construction.

Dihydrate gypsum (CaSO4·2H2O) is also known as raw gypsum. After calcination and grinding, β-type hemihydrate gypsum (2CaSO4·H2O) can be obtained, namely, building gypsum, also known as plaster of paris and plaster. If the calcination temperature is 190℃, model gypsum can be obtained, and its fineness and whiteness are higher than building gypsum. If the green gypsum is calcined at 400-500°C or higher than 800°C, floor gypsum is obtained. The setting and hardening are slower, but the strength, wear resistance and water resistance after hardening are better than ordinary building gypsum.

The industrial by-product gypsum is fed into the steam tube bundle calcining kiln through box feeder, belt conveyor, vibrating feeder and other conveying equipment, and then calcined under 240 ℃ supersaturated steam; The calcined products are sent to the cooling bin for cooling through conveying equipment such as screw conveyor and plate chain elevator; The cooled semi-finished products are sent to the ex-grinding bin through screw conveyor, belt conveyor, plate chain elevator and other conveying equipment, and then sent to the ball mill for grinding after metering; The milled finished products are sent to the finished product warehouse for storage; After the finished product warehouse, a packaging machine can be set for packaging and sale, or the powder material can be directly transported by bulk truck to customers.


Main Equipment Configuration Table
Main EquipmentMain equipment models, and technical & economic index
Rotary KilnØ2.0×24mØ2.4×24mØ2.8×26mØ3.0×26mØ3.2×26mØ3.4×28mØ3.6×28mØ4.0×28m
Plaster MillØ1.2×4.5mØ1.5×5.7mØ1.83×5.5mØ2.1×6.5mØ2.2×6.5mØ2.4×7mØ2.4×8mØ2.6×8m
Bag FilterPPC96-6PPC96-8PPC128-6PPC128-9PPC96-2x9PPC128-2x7PPC128-2x9PPC128-2x12
Production Raw Material Requirementscalcium sulfate dihydrate content (dry basis) ≥90%, adhesion water content≤15%, water-soIubIe magnesium oxide (dry basis)≤0.5% PH vaIue 6-8 , chIoride ion content (dry basis)≤500mg/kg
CaIcination Temperature/"C150
Energy Consumption lndex/(kg/t lime)500±50
Power Consumption lndex/(kw•h/t lime)25±5
Desulfurization Gypsum: Gypsum Powder1.4:1
Setting TimeInitial solidification≥8min, termination of solidification≤30min
Strength (Mpa)2 hours flexural strength≥3.0M Pa; compressive strength≥6.5MPa;
Three-phase ControlDihydrate gypsum is less than 3%, hemihydrate gypsum is greater than 84%, and soluble anhydrous gypsum is less than 3%;
mission Concentration / (mg/m3≤30
Annual Working Day / days≥300
Overhaul Cycle/Year3
Applicable FuelSteam, natural gas, pulverized coal
